Products

Low Voltage Distribution Boxes & Control Cabinets

Junray Electrical supplies low voltage distribution boxes and control cabinets for electrical distributors, industrial contractors and project procurement teams. Compare JXF enclosures, PLC control cabinets and PZ30 terminal distribution boxes by circuit function, installation conditions and the approved project specification.


Which Distribution Box or Control Cabinet Fits Your Project?

Start with the circuit schedule and single-line diagram. Confirm rated voltage and frequency, incoming and outgoing circuits, current, protection devices, mounting method and required dimensions. Product ratings depend on the selected model and assembled configuration; a category name is not a shared rating for every box.

JXF control boxes: Compare the JXF steel control box and JXF 304 stainless steel control box. Specify enclosure dimensions, door arrangement, cable entries, mounting plate, component layout and the required protection rating. Confirm suitability for salt exposure, washdown or outdoor service for the quoted assembly.

PLC control cabinets: Provide the I/O list, control sequence, communication interfaces, connected loads and panel layout. The PLC control cabinet page lists configuration options; confirm the controller, power supply, terminal allocation, wiring drawings and software scope before ordering.

PZ30 distribution boxes: The PZ30 distribution box is listed for AC 220/380 V terminal distribution, with IP30 protection for dry indoor installation. Select the circuit count, incoming device, outgoing breakers and flush or surface mounting. Confirm the model against the project supply; this is not a weatherproof outdoor enclosure.

Other distribution functions: Compare XL-21 power distribution boxes, JP distribution cabinets and GGD fixed switchgear when the project requires a different feeder, metering or cabinet arrangement. Use the relevant product datasheet rather than transferring one model's specifications to another.


What Site Conditions Should Buyers Specify?

Describe the installation environment before selecting an enclosure. The same product family may require different materials, ventilation, component ratings or protection arrangements for different sites.

Middle East projects: State maximum ambient temperature, direct solar exposure, dust or sand conditions, altitude and indoor or outdoor location. Ask for confirmation of heat dissipation, any current derating and the protection rating of the assembled cabinet.

South America projects: State the destination country, utility or client requirements, supply voltage, frequency, earthing system, altitude, humidity and any coastal exposure. Voltage and frequency must be confirmed for the actual site rather than assumed from the region.

Industrial control: Give motor or process loads, start and stop logic, interlocks, alarms and communication requirements. Separate the enclosure supply scope from the complete wired and programmed control cabinet scope.

Commercial and residential distribution: Provide the final circuit schedule, breaker poles, neutral and protective-earth arrangements, installation dimensions and access requirements for maintenance.

Outdoor distribution and metering: Confirm corrosion exposure, drainage, cable entry direction, meter requirements and installation responsibility. Enclosure selection does not replace the project's protection, earthing or site engineering.


Request a Distribution Box or Control Cabinet Quotation

Send a single RFQ package so the proposed configuration and quotation can be compared against the same requirements. For the broader range, see low voltage switchgear.

Technical inputs: Product or model, voltage and frequency, current, circuit quantity, component preferences, dimensions, protection rating, environmental conditions and a single-line diagram or control drawing where available.

Documentation: Specify the drawings, wiring diagrams, component list and inspection or test records required for review. Confirm the applicable standard and evidence for the offered configuration; do not treat a general standards reference as product certification.

Commercial inputs: Quantity, destination country, required delivery date, packing requirements and the scope of installation or commissioning support. Identify whether you need an empty enclosure or a complete assembled panel.

Request a low voltage distribution box quotation with your project details, or contact dylan@junrayelectrical.com / WhatsApp +86 150 6777 8855 for configuration review.

View as

PZ30 Distribution Box

PZ30 Distribution Box

Junray PZ30 distribution boxes are indoor terminal distribution enclosures for residential, commercial and building-services projects. Listed ratings are AC 220 V / 380 V, up to 63 A and IP30 for dry indoor locations, with surface or recessed mounting and 4–36 circuit options. Electrical contractors and distributors should confirm the circuit schedule, module space, installed protective devices and enclosure dimensions. Send quantity and destination country for a project quotation.
JXF Control Box

JXF Control Box

The Junray JXF control box uses a powder-coated cold-rolled steel enclosure for indoor electrical control assemblies. The listed configuration is AC 380 V / 220 V, 50 Hz with IP40 protection and surface or recessed mounting options. Panel builders and electrical contractors should specify enclosure dimensions, mounting, circuit requirements and whether an empty enclosure or wired assembly is needed. Send quantity and destination country for a project quotation.
XL-21 Type Power Distribution Box

XL-21 Type Power Distribution Box

The XL-21 Type Power Distribution Box of Junray Electrical is an indoor low-voltage floor-standing standard power distribution device. It is strictly designed and manufactured in accordance with national standards. It is made of thickened cold-rolled steel plates, which are bent, welded, and coated with electrostatic paint through meticulous processing. The cabinet structure is stable and the space is ample. It can be equipped with circuit breakers, contactors, transformers, meters and other electrical components. It is mainly used for power and lighting distribution systems with an alternating current frequency of 50Hz and a rated voltage of 380V or below, achieving control, protection and monitoring of power and lighting distribution. It is widely applicable in factory workshops, commercial buildings, municipal engineering, substations and other scenarios. It is easy to install, safe and stable, and is a core standard equipment for industrial power distribution.
JP Distribution Cabinet

JP Distribution Cabinet

The Junray JP distribution cabinet combines low-voltage feeder distribution, metering and reactive power compensation in one outdoor assembly. The listed configuration is AC 380 V, 50 Hz with IP54 protection. It is intended for electrical contractors, EPC procurement teams and distributors selecting cabinets for transformer-side distribution. Send the required voltage, frequency, feeder schedule, quantity and destination country for a project quotation.
GGD Voltage Switchgear

GGD Voltage Switchgear

Junray Electrical is a professional manufacturer and supplier of Low-Voltage Switchgear in China. GGD Voltage Switchgear is a core low-voltage distribution equipment for the distribution room, strictly manufactured in accordance with national standards for low-voltage complete switchgear. It is specifically designed for large-scale low-voltage distribution systems with an alternating current of 50Hz, a rated voltage of 380V, and a rated current up to 3150A. It is used as the outgoing line, incoming line, and metering cabinet of the distribution room, enabling the distribution, control, and protection of large currents. It is widely applicable to large-scale factories, data centers, commercial complexes, substations, and other scenarios requiring large current distribution. It is the standard standard equipment for large-scale low-voltage distribution systems and perfectly complies with engineering acceptance standards.
GGJ Reactive Power Compensation Cabinet

GGJ Reactive Power Compensation Cabinet

Junray Electrical is a manufacturer and supplier of professional GGJ Reactive Power Compensation Cabinets in China. This is a factory-specific energy-saving compensation device that can automatically compensate for the reactive power of the power distribution system, increasing the power factor from below 0.8 to above 0.95. It completely eliminates reactive power penalties, reduces line losses, improves transformer load rate, suppresses harmonics, protects equipment, adapts to fluctuating loads of the factory, helps the factory save electricity costs and installation capacity costs, and is widely used in high-energy-consuming factories, production lines, and other scenarios. It is intelligent, convenient, and has a long lifespan.
Junray Electrical is a professional Low-Voltage Distribution Box manufacturer and supplier in China. We warmly welcome you to wholesale high quality products at competitive price from our factory.
